Unit : mm
| Model No. | BOLT Dia( A ) | B | C | D | Thread ( E ) | Material | Surface Treatment |
| SWS6411A | ∅8 | 39.5 | 15.8 | 5.5 | M8X1.25 | SUS303 | Vibratory Grinding |
| SWS6411B | 44.5 | 15.8 | 10.5 | ||||
| SWS6411C | ∅10 | 41.5 | 15.8 | 5.5 | M10X.15 | ||
| SWS6411D | 46.5 | 15.8 | 10.5 |
Ball Studs
SWS6411(SUS303)
SWS6411(SUS303)
DETAIL
Unit : mm
