Unit : mm
| Model No. | Ball Dia. ( A ) | B | C | D | E | Thread ( F ) | Material | Surface Treatment |
| SWS-8 SUS303 | ∅10 | 14 | 3 | 13 | 8 | M6X1.0 | SUS303 | Vibratory Grinding |
| SW11 BLACK ZINC | 14.2 | 4.9 | 12.5 | 12 | 12L14 | Black Zinc Plated | ||
| SW12 BLACK ZINC | 14 | 4.5 | 13.5 | 12 | M8X1.25 | 12L14 | Black Zinc Plated | |
| SWS-12 SUS303 | SUS303 | Vibratory Grinding | ||||||
| SW13 BLACK ZINC | 12.5 | 3 | 12.5 | 13 | 12L14 | Black Zinc Plated | ||
| SWS-13 SUS303 | SUS303 | Vibratory Grinding | ||||||
| SW177583 BLACK ZINC | 12 | 3 | 16.5 | 13 | 12L14 | Black Zinc Plated |
