1022-C920(Hole 10mm)

1022-C920(Hole 10mm)

STABILUS (Gas Spring Free Type-Safety Series)
Specification:
Rod Dia. : 10mm / Tube Dia. : 22mm
Material: carbon steel / Operating temperature: -30℃~80℃
Rod Surface treatment: Hard Chrome Plated or Nitrided Black / Tube Surface treatment: Black Coated
Length unit: mm / Force unit: 1 kg=9.8(N) Newton=2.2 lbs
/
DETAIL

Unit：mm
9.8 Newton(N)=1 Kg=2.2 LBS
Model No. Stroke (A) Extended Length (B) Force Range (N)
SB3-285-C920-XXXNPK 65 285  100～1150N
SB3-330-C920-XXXNPK 90 330  100～1150N
SB3-385-C920-XXXNPK 115 385  100～1150N
SB3-405-C920-XXXNPK 125 405  100～1150N
SB3-450-C920-XXXNPK 145 450  100～1150N
SB3-485-C920-XXXNPK 165 485  100～1150N
SB3-500-C920-XXXNPK 175 500   100～1150N
SB3-525-C920-XXXNPK 185 525   100～1150N
SB3-585-C920-XXXNPK 215 585  100～1150N
SB3-670-C920-XXXNPK 245 670  100～1150N
SB3-685-C920-XXXNPK 265 685  100～1150N
SB3-700-C920-XXXNPK 265 700  100～1150N
SB3-750-C920-XXXNPK 295 750  100～1150N
SB3-785-C920-XXXNPK 315 785  100～1150N
SB3-830-C920-XXXNPK 335 830  100～1150N
SB3-885-C920-XXXNPK 365 885  100～1150N

STABILUS Free Type-Safety Gas spring works on the same principle as free type but with additional support tube and outer lock to secure mechanical BLOC-O-LIFT of the application in the open position.
