0818-C920(Hole 10mm)

0818-C920(Hole 10mm)

STABILUS (Gas Spring Free Type-Safety Series)
Specification:
Rod Dia. : 08mm / Tube Dia. : 18mm
Material: carbon steel / Operating temperature: -30℃~80℃
Rod Surface treatment: Hard Chrome Plated or Nitrided Black / Tube Surface treatment: Black Coated
Length unit: mm / Force unit: 1 kg=9.8(N) Newton=2.2 lbs
/
DETAIL

Unit：mm
9.8 Newton(N)=1 Kg=2.2 LBS
Model No. Stroke (A) Extended Length (B) Force Range (N)
SB2-205-C920-XXXNPK 25 205 100~650N
SB2-245-C920-XXXNPK 45 245 100~650N
SB2-285-C920-XXXNPK 65 285 100~650N
SB2-295-C920-XXXNPK 65 295 100~650N
SB2-330-C920-XXXNPK 90 330 100~650N
SB2-375-C920-XXXNPK 113 375 100~650N
SB2-405-C920-XXXNPK 130 405 100~650N
SB2-430-C920-XXXNPK 142 430 100~650N
SB2-450-C920-XXXNPK 150 450 100~650N
SB2-485-C920-XXXNPK 165 485 100~650N
SB2-500-C920-XXXNPK 175 500 100~650N
SB2-525-C920-XXXNPK 190 525 100~650N
SB2-585-C920-XXXNPK 215 585 100~650N
SB2-630-C920-XXXNPK 240 630 100~650N

STABILUS Free Type-Safety Gas spring works on the same principle as free type but with additional support tube and outer lock to secure mechanical BLOC-O-LIFT of the application in the open position.
