0818-B10(Hole 10mm)

0818-B10(Hole 10mm)

STABILUS LIFT-O-MAT
Specification:
Rod Dia. : 08mm / Tube Dia. : 18mm
Material: carbon steel / Operating temperature: -30℃~80℃
Rod Surface treatment: Hard Chrome Plated or Nitrided Black / Tube Surface treatment: Black Coated
Length unit: mm / Force unit: 1 kg=9.8(N) Newton=2.2 lbs
/
DETAIL

Unit：mm
9.8 Newton(N)=1 Kg=2.2 LBS
Model No. Stroke (A) Extended Length (B) Force Range (N)
SB2-205-B10-XXXN 60 205 100~650N
SB2-245-B10-XXXN 80 245 100~650N
SB2-285-B10-XXXN 100 285 100~650N
SB2-295-B10-XXXN 100 295 100~650N
SB2-325-B10-XXXN 120 325 100~650N
SB2-330-B10-XXXN 125 330 100~650N
SB2-365-B10-XXXN 140 365 100~650N
SB2-375-B10-XXXN 148 375 100~650N
SB2-405-B10-XXXN 165 405 100~650N
SB2-430-B10-XXXN 177 430 100~650N
SB2-445-B10-XXXN 180 445 100~650N
SB2-450-B10-XXXN 185 450 100~650N
SB2-485-B10-XXXN 200 485 100~650N
SB2-500-B10-XXXN 210 500 100~650N
SB2-525-B10-XXXN 225 525 100~650N
SB2-585-B10-XXXN 250 585 100~650N
SB2-630-B10-XXXN 275 630 100~650N

STABILUS LIFT-O-MAT Free Type gas spring can lift and adjust application but no positioning function.
With certain Nitrogen (N2) & oil filled inside to make reaction force when gas spring is compressed. Products in this line protect materials by preventing the full weight of the application from acting on the hinges and joints to make the component travel is altogether more harmonious and easier to control as well.
For extension damping, the gas spring is installed vertically with the piston rod oriented downward.
