S0818-C9S20(Hole 10mm)

S0818-C9S20(Hole 10mm)

Stainless SUS316 Gas Spring Free Type
Specification:
Rod Dia. : 08mm / Tube Dia. : 18mm
Material: Stainless 316L / Operating temperature: -30℃~80℃
Rod Surface treatment: Stainless 316L / Tube Surface treatment: Stainless 316L
Length unit: mm / Force unit: 1 kg=9.8(N) Newton=2.2 lbs
/
DETAIL

Unit：mm
9.8 Newton(N)=1 Kg=2.2 LBS
Model No. Stroke (A) Extended Length (B) Force Range (N)
BS060205-C9S20-XXXN 60 205 100~650N
BS080245-C9S20-XXXN 80 245 100~650N
BS100285-C9S20-XXXN 100 285 100~650N
BS120325-C9S20-XXXN 120 325 100~650N
BS140365-C9S20-XXXN 140 365 100~650N
BS160405-C9S20-XXXN 160 405 100~650N
BS180445-C9S20-XXXN 180 445 100~650N
BS200485-C9S20-XXXN 200 485 100~650N
BS220525-C9S20-XXXN 220 525 100~650N
BS250585-C9S20-XXXN 250 585 100~650N

LIFT-O-MAT Stainless SUS316 Gas Spring Free Type can lift and adjust application but no positioning function.
With certain Nitrogen (N2) & oil filled inside to make reaction force when gas spring is compressed. Products in this line protect materials by preventing the full weight of the application from acting on the hinges and joints to make the component travel is altogether more harmonious and easier to control as well.
For extension damping, the gas spring is installed vertically with the piston rod oriented downward.
